Green Pin® Bow Shackle SC (Standard Shackle with Screw Collar Pin)

Van Beest

Standard Shackle with Screw Collar Pin

• Material: bow and pin high tensile steel, grade 6, quenched and tempered

• Safety Factor: MBL equals 6 x WLL

• Standard: EN 13889 and meets performance requirements of US Fed. Spec. RR-C-271 Type IVA Class 2, grade A, from 2 t and upward these shackles comply with.    ASME B30.26

• Finish: hot dipped galvanized

• Temperature Range: -40°C up to +200°C

• Certification: 2.1 2.2 3.1 MTC a DNV GL 0378 CE ABS PDA ABS MA
